GitHub – Antirez/c64-Hw-Simulator: Commodore 64 Hardware Simulator
The c64-hw-simulator is a detailed pin-level hardware simulator of the Commodore 64 motherboard (ASSY 250407), allowing users to manipulate individual chip pins, pull chips from sockets, or open circuit elements to observe the resulting effects on the system’s behavior, including video output and signals. It models the board’s netlist and chip pin behaviors, integrating cycle-accurate cores for key chips and simulating electrical phenomena like drive strengths, floating nets with drift and noise, and power faults, enabling fault analysis and learning without risking real hardware damage. While comprehensive, the simulator runs slower than real time and does not simulate internal chip faults or analog components like the video output and power supply.
GitHub – Antirez/c64-Hw-Simulator: Commodore 64 Hardware Simulator Read More »
